Description
V.E.M. HVLS Commercial Ceiling Fan 4.2M Blade
● Customized development for commercial scenes, optimize the product structure, new appearance design;
● The fan is exquisite, beautiful, easy to install and use;
● With a diameter of 3 meters and a power of only 260w, it drives a large area of air flow, effectively improving the working environment and improving personnel comfort.
● Suitable for gym, 4S shop, large supermarkets, office buildings, restaurants, playground, terminal building and other commercial leisure places
Five Core Technologies
|
1) Power Technology
● Permanent magnet external rotor motor,high efficiency and energy saving, small volume and light weight.
● (patent) labyrinth type dust-proof structure to prevent dust from entering motor core part.
● (patent) motor core heat dissipation system, low temperature rise, long service life.
|
2) Blade Technology
Blade adopts high-strength aluminum alloy material, high lift drag ratio aviation airfoil design.
|
|
|
3) Safety Technology
● Adopt 12 major safety protection designs.
● Steel beam locking safety structure protection.
● Hanger safety steel cable protection.
● Motor shaft safety bracket protection.
● Anti-drop safety structure protection in the motor end cover.
● Step lock safety design inside the motor.
● Permanent magnet self-locking safety protection.
|
● Reinforced blade mounting bracket.
● Blade safety link mechanism protection.
● Control system overload protection.
● Grade 12.9 high strength fasteners.
● Anti-loosening washer and thread anti-loosening
glue achieve at double protection.
● The blade is made of non-metal polymer composite material,
which is impact resistant and not easy to break. |
4) Control Technology
● Developed in cooperation with professional manufacturer of frequency converter, with over-current protection, over- voltage / under-voltage protection, overload protection, and effective matching with fans. Start, accelerate, decelerate, stop softly without impact, it can effectively reduce vibration and noise.
|
|
|
5) Wingtip Technology
● Install patent designed wingtip guide plate.
● Effectively reduce the air to be vortex in the movement of theend of streamlined blade.
● Reduce the energy loss caused by vortex and improveefficiency; Stable operation effectively reduces noise.
|
Application Case
Suitable for workshop, logistics storage, gymnasium, stadium, exhibition center, shopping mall and station etc. for ventilation and cooling.
|
Factory Workshop
|
Stadium
|
Rail Traffic
|
|
Spare Parts Workshop
|
Logistics Warehouse
|
Outdoors
|
|
Aerospace
|
Amusement Park
|
Gym
|
Download Datasheet
Download User Manual
