Description
Male Ball Joint Assembly With Stud
Bearing Raceway – Locked in by annular groove-trunion design.Made of fiber reinforced nylon.
Threaded Stud – Made from medium carbon steel.
Spherical Ball – Precision made from selected low carbon steel-casehardened – file hard. Plated plus dichromate treated for corrosion resistance.
Outer Member (Housing) – Low carbon steel, plated plus dichromate treated for corrosion resistance.
Dimensions
| Thread Size (A) | B | C | D | E | F | G | H | J | K | L | M | N | Thread |
| 1/4-28 | .469 | .562 | .156 | .750 | .375 | 1.562 | 1.000 | 1.937 | .250 | .516 | .281 | .375 | L |
1 Per Package
