Rod End Ball Joint Female W/Stud 10-32 (L)
Sale!
clipsandfasteners2026022413520649291

Rod End Ball Joint Female W/Stud 10-32 (L)

Original price was: $28.28.Current price is: $8.48.

SKU: 489191308 Category:

Description

  • Rod End Ball Joints (Female with Stud)
  • Bearing Raceway – Locked in by annular groove – trunion design. Made of fiber reinforced nylon
  • Threaded Stud – Made from medium carbon steel
  • Spherical Ball – Precision make from selected low carbon steel – case hardened – file hard. Plated plus dichromate treated for corrosion resistance
  • Outer Member (Housing) – Low carbon steel, plated plus dichromate treated for corrosion resistance
  • Only Available Fully Assembled
  • Dimensions:
    • Thread Size (A): 10-32
    • B: 0.437
    • C: 0.437
    • D: 0.156
    • E: 0.625
    • F: 0.312
    • G: 1.062
    • H: 0.562
    • J: 1.375
    • K: 0.189
    • L: 0.438
    • M: 0.250
    • N: 0.312
    • O: 0.406
    • P: 0.312
    • R: 0.406
    • The.: L
  • 1 Per Package

    View Catalog Page
