Description
Metal Conduit Nipples Cap – Zinc Die-Cast
Metal Conduit Nipple Caps along with a rigid coupling to terminate a run of threaded conduit into an enclosure box. This zinc encased nipple is rated for both indoor and outdoor use and is corrosion resistant.
Specifications
Specifications
| Part Number | Trade Size | Dim A | Dim B | Dim C |
|---|---|---|---|---|
| NPNB-501 | 1/2″ | .585 | .425 | 1.050 |
| NPNB-502 | 3/4″ | .614 | .514 | 1.310 |
| NPNB-503 | 1″ | .654 | .518 | 1.616 |
| NPNB-503 | 1″ | .654 | .518 | 1.616 |
| NPNB-504 | 1-1/4″ | .810 | .578 | 1.978 |
| NPNB-505 | 1-1/2″ | .835 | .613 | 2.410 |
| NPNB-506 | 2″ | .888 | .676 | 2.945 |
| NPNB-507 | 2-1/2″ | 1.200 | .876 | 3.555 |
| NPNB-503 | 3″ | 1.375 | 1.008 | 4.390 |
| NPNB-509 | 3-1/2″ | 1.375 | 1.008 | 4.925 |
| NPNB-510 | 4″ | 1.375 | 1.011 | 5.420 |
| NPNB-511* | 5″ | 1.700 | 1.232 | 5.812 |
| NPNB-512* | 6″ | 2.000 | 1.500 | 7.000 |
| * Malleable |
What’s in the box?
What’s in the box?
- Qty 1 – Metal Conduit Nipples Cap – Zinc Die-Cast
