Description
Male Ball Joint Assembly With Stud
Bearing Raceway – Locked in by annular groove-trunion design.Made of fiber reinforced nylon.
Threaded Stud – Made from medium carbon steel.
Spherical Ball – Precision made from selected low carbon steel-casehardened – file hard. Plated plus dichromate treated for corrosion resistance.
Outer Member (Housing) – Low carbon steel, plated plus dichromate treated for corrosion resistance.
Dimensions
| Thread Size (A) | B | C | D | E | F | G | H | J | K | L | M | N | Thread |
| 1/2-20 | .875 | 1.125 | .312 | 1.312 | .625 | 2.437 | 1.500 | 3.094 | .500 | .938 | .500 | .625 | R |
1 Per Package
