Description
Optimized 3-Phase Metering for 200A Systems.
The Dixsen QC3N1-35/28 is a specialized 3-in-1 Current Transformer designed to streamline power monitoring in mid-range distribution panels.
Rated for 200 Amps, this unit integrates three current transformers into one compact housing. The “35/28” window design is engineered to fit perfectly around standard busbars or larger gauge cables, ensuring a secure and professional installation without the bulk of three separate CTs.
With Class 1.0 accuracy, this transformer provides the precise measurements required for energy billing, cost allocation, and detailed power analysis. The increased 1.5VA burden ensures reliable signal transmission to your metering equipment.
Key Features:
- Busbar Optimized: The 35/28mm aperture is sized for standard 200A busbar or cable configurations.
- 3-in-1 Efficiency: Monitors all three phases (L1, L2, L3) in a single unit, reducing installation time and wiring errors.
- Precision Metering: Rated Class 1.0 for accurate energy consumption tracking (kWh).
- Enhanced Signal: A 1.5 VA burden supports standard metering devices and longer wiring runs.
Technical Specifications:
| Feature | Specification |
| Model | QC3N1-35/28 |
| Primary Current | 200 A |
| Secondary Current | 5 A |
| Accuracy Class | 1.0 |
| Rated Burden | 1.5 VA |
| Configuration | 3-Phase (3-in-1) |
| Frequency | 50/60 Hz |
