DisplayPort Male to VGA Female Adapter

Description

DisplayPort Male to VGA Female Adapter

The DisplayPort VGA adapter enable you to connect any VGA interface embedded device (Monitor, Projector, etc.) with a DisplayPort interface (Desktop, Laptop).

Features

Features

• Cable length: 1 1/2″
• Gold plated connector
• House and cable color: White

Specifications

Specifications

• Compliance with DisplayPort Specification V1.1a at 1.62/2.7Gbps data rate (Low bit rate/High bit rate)
• Protocol: Support DPCD Rev.1.1 & Support HDCP 1.3 with HDCP key embedded
• Resolution: up to 1920X1200 / 1080p
• Connector DP male to VGA female
• Total Length: 7″ (connector edge to edge)
• Connector housing dimensions:
• VGA side: 3 (L) x 1-1/2 (W) x 3/4″ (H)
• DP side: 1-7/8 (L) x 3/4 (W) x 1/2″ (H)

What’s In the Box

What’s In The Box

• Qty 1 – DisplayPort Male to VGA Female Adapter
