Description
Former Part Number: CN1-6788-Z6
Easy Feed Unshielded RJ45 Connector – CAT6
The CAT6 Easy Feed RJ45 Modular Plug is the must have connector for all datacom and telecom installers. This RJ45 Plug saves time and money with it’s simple easy to use design. Installers can simply slide all the conductors through the jack at once making it clear to verify proper wire alignment before termination. These connectors place the twisted wire pairs straight inline to one another and prevent staggering. Connectivity is vital when installing a network so be sure to get these quality plugs on all your CAT6 Cables.
Please consider us for any of your other networking needs. We’ve got bulk cable, many styles of keystone jacks, and other items. Thank You.
Features
Features
- Feed Through CAT6 8×8 RJ45 Modular Plug
- For Round Solid or Stranded Cable
- Compatible With 23 AWG – 26 AWG Cables (OD Under 6.5mm)
- 50 Micro-inch Gold Plated Contacts
- Wires Inserted Through Front of Connector
- Strain Relief Bar Secures Connector Around Cable
- Faster Terminations With Reduced Scrap
- Simple One-piece Design
- UL Rated
- Transparent Housing for Easy Conductor Alignment
- Operation Temperature: -20°C – +50°C
- Fits an Insulation Diameter of 0.93mm ~ 1.04mm
Specifications
Specifications
Additional Information
Additional Information
What’s in the Box
What’s in the Box
- Qty 1 – CAT6 Easy Feed RJ45 Connector(25 Pack bag)
- Qty 1 – CAT6 Easy Feed RJ45 Connector(50 Pack bag)
- Qty 1 – CAT6 Easy Feed RJ45 Connector(100 Pack Jar)
