Description
Compatible with Cisco switches.
25GBASE-ER SFP28 Module SMF 40km FEC
This Product is programmed to be fully compatible and functional with all intended Cisco switching devices. This SFP module is based on the 25G Ethernet IEEE 802.3by standard and is designed to be compliant with the SFP Multi-source Agreement (MSA). This module is designed for Single mode fiber and operates at a nominal wavelength of 1310nm.
Features
Features
- Supports up to 25 GbE for high-speed data transfer and efficient network performance.
- Hot-pluggable SFP28 footprint
- Operates at 1310 nm for optimal signal transmission
- Duplex LC connector
- Built-in digital diagnostic function
- power supply 1v
- Operating temperature ranges from 0°C to 70°C
Specification
Specification
| Form Factor | SFP28 |
| Max Data Rate | 25GbE |
| Wavelength | 1310nm |
| Max Cable Distance | 40km over SMF |
| Connector | 1 X LC Duplex UPC |
| DOM Support | YES |
| Power Supply | 1v |
| Operational Temperature Range | 0°C to +70°C |
What’s in the Box
What’s in the Box
- Qty 1 – SFP28 25GBASE‑ER Optical Transceiver Module (LC duplex connector)
- Qty 2 – LC Duplex Dust Plugs to protect transceiver ports
- Qty 1 – Anti‑Static (ESD‑Safe) Protective Bag
- Qty 1 – Foam Tray or Clamshell Insert for cushioning inside the outer carton
- Qty 1 – Label or Quick‑Start Insert showing model, serial number, and basic install guidelines
