Description
Security Alarm Cable 18/4 (7 Strand) Plenum CMP Rated Shielded 1000′ ft
Our 18 AWG 4-Conductor Security Alarm Cable, tailored for security systems, suits intercoms, power-limited controls, and sound/audio systems. Made in the USA, it boasts 7 strands of bare copper and a shielded Plenum CMP-Rated white jacket. Supplied in 1000 ft. increments, this cable blends quality with convenience.
Our Bulk Security Alarm Cables, or alarm wire, are intricately crafted to meet installation needs. With riser and plenum-rated jackets available, we cater to diverse requirements. Ensure compliance with building codes before purchase. Featuring print legends for quick identification, these cables save installation time, making them a preferred choice for various applications.
Explore our portfolio of high-quality security cables
Plenum – CMP
Shielded Plenum – CMP
Unshielded Riser – CMR
Shielded Riser – CMR
Unshielded Outdoor – CMX
Water Block
Applications
A broad range of applications exist for bulk plenum security alarm cabling. It is widely used with security systems, intercom systems, sound/audio systems, and power-limited controls in commercial settings such as schools, universities, hospitals, airports, government buildings, train and transportation centers, stadiums, and arenas. Since this security cable has multiple conductors under one jacket, the preparation, setup, and termination time is shorter.
Features
Features
- 18 AWG 4 Conductors
- 7 Stranded Bare Copper Conductors
- Low Smoke PVC Insulation
- AL Foil Shielded
- Low Smoke White PVC Jacket
- Sequential Footage Marking
- CL3P, CMP FT6 Rated
- ETL Listed
- RoHS Compliant
- NEC Articles
- 22-16 AWG: FPLP/760, CMP/800, CL3P, CL2P/725
- 14-12 AWG: FPLP, CL3P
Residential Or Commercial Applications
- Security Systems
- Intercom Systems
- Sound/Audio Systems
- Power-Limited Controls
Specifications
Specifications
| Physical Construction | |
|---|---|
| Inner Conductor | Stranded Bare Copper |
| Conductor Size | 18 AWG |
| Insulation | PVC |
| Nominal OD | 4.85mm |
| Outer Jacket Diameter | .38mm |
| Jacket | Low Smoke PVC |
| Jacket Color | White |
| Number of Strands | 7 |
| Inner Conductor Diameter | 1.2mm |
| Electrical Characteristics | |
|---|---|
| Temperature | 75°C |
| Voltage Rating | 300V |
| Center Resistance | 21.20 (Ω/km) |
| Additional Information | |
|---|---|
| Standards | ETL | RoHS | CMP | CL3P |
| Applications | Security Systems | Intercom Systems Sound | Audio Systems | Power-Limited Controls |
| Jacket Printing | 22 AWG 6C (ETL) 725/CL3P 800/CMP (VID:###) XXXX FT |
| Important Notes | The information contained in this document is proprietary to CRN Solutions and may not be disclosed or transmitted to any other parties without the express written permission of CRN Solutions. This information is provided for the purposes of quotation only. |
